Product Details:
Place of Origin:CHINA
Brand Name:YIHUA
Certification:CE,ISO, SASO
Model Number:API-94
Payment & Shipping Terms:
Minimum Order Quantity:1 PCS
Price:Negotiate
Packaging Details:NUDE PACKING,PLYWOOD CASE
Delivery Time:25 DAYS
Payment Terms:L/C, D/P, T/T
Supply Ability:10000SETS/YEAR

Description

Materials:SteelType:Mobile Trailer Generator
Place Of Origin:Fujian, ChinaPhase:Three
Color:Any Color You WantGenset Power:94KVA 75KW
Genset Option:Fuel System External Fuel FillingGenset Option 2:Auto Refilling Diesel System
Genset Option 3:External Fuel Filling DeviceGenset Option 4:Fuel Level Gauge
High Light:

75KW Mobile Electric Power Generators

,

94 KVA Mobile Electric Power Generators

,

35A 3 phase mobile generator

Heavy Duty Industrial Type 94KVA Mobile Genset Trailer Ac 3 Phase 50hz Trailer Generator



Product descriptions :



Engine Brand: ISUZU

Number of Cylinders: 6

Cylinders Arrangerment: Vertical in-line

Aspiration: Turbo & Inter cooler

Starting method: Electric motor start

Type : 6-cylinder,In-line,Water cooled,Four-stroke,Turbo & Inter cooler

Governing Type: Mech

Governor Regulation

Coolant Capacity (L): 30

Rotation direction (face to the flyweel): Anticlockwise

The lowest stable speed at zero load (r/min): ≦ 1000

Starting motor capactiy (V.kw): 24V 3.7KW

Charging generator capactiy (V.A): 28V 35A

Accumulator capacity (V.Ah): 24V 120Ah

Alternator: ACEPOW Brushless alternator

Conttrol System: Separaately Excited BY P.M.G.

Insulatiion System : Class H

Protection: IP23

Rated Power Factor: 0.8

Stator Winding: Double Layer Concentric

Winding Pitch: Two Thirds

Winding Leads : 12

Stator Wdg.Resistance: 0.044 Ohms Per Phase At 22°C Series Star Connected

Rotor Wdg.Resistance: 1.26 Ohms at 22°C

Exciter Stator Resiistance: 20 Ohms at 22°C

Exciter Rotorr Resisttance: 0.091 Ohms Per Phase At 22°C

R.F.I. Suppression: BS EN 61000-6-2 & BS EN 61000-6-4,VDE 0875G, VDE 0875N. refer to factory for others



Output Ratings
Generating Set ModelPrime
API-9494KVA/75KW
Ratings and Performance Data
Engine BrandISUZU
Engine Model6BG1-Z1
Alternator BrandStamford
Alternator ModelUC274C / UCI274C
Fuel Consumption rate (g/kW.h)231
Model TypeOpen / Silent
Standard PackagePlywood case/ Plastic
Noise Level@7m (dBA)70
Generator set ManufactureAcepow
Oil Consummption (g/kW.h)≦0.4
Volatage (V)220/230/240
Silencer Noise Reduction (dBA)10-20
Engine Technical Data
Engine Model6BG1-Z1
Engine BrandISUZU
Number of Cylinders6
Cylinders ArrangermentVertical in-line
Bore/Stroke (mm)105*125
Fuel System
Fuel TankSteel
Fuel Tank Capacity (L)
Fuel tank typeBottom
Recommended Fuel Type0# or ASTM2
Injection SystemDirect injection

6 Cylinders 3 Phase Mobile Electric Power Generators 0
