Description
| Output Type: | AC Three Phase/ Single Phase | Control Panel: | Deepsea / ComAp / Harsen / Smartgen 6110 |
|---|---|---|---|
| Type: | Standby Diesel Generator | Rated Power: | 80KW/100KVA |
| Alternator: | Stamford/Leroy Somer/Marathon | Cooling Method: | Water-cooled |
| Generator Type: | Silence Generator Set,Silent(super Silent)or Open Gene | Warranty: | 12 Months |
| Noise: | 70-75dB | Fuel Tank: | 0ver 8 Running Hours Fuel Tank |
| Rated Current: | Cheap Diesel Generator | ||
| High Light: |
80KW Diesel Home Standby Generator, 100KVA Diesel Home Standby Generator, 1500RPM heavy duty silent diesel generator |
||
Home Use Small Standby Diesel Generator 100kva 80kw Shangchai Generator Set Pricelist Three Phase Or Single Phase
Standard configuration :
Engine: Shangchai
Alternator: Stamford/Leroy Somer/Marathon
Cooling Fan with fan guard and front guard
Alternator: Single bearing, IP23, H class
24V Charger
Shock Absorber
Dry Air Filter. Dual Fuel Filter. Engine Oil Filter Coolant Filter.
MCCB Circuit Breaker
Standard Control Panel; ATS for optional
Start Battery with connecting cable
Storage Battery and battery line, Exhaust pipe,Corrugated pipe for anti-vibration, Cone Tube,Flange, Muffler
Soundproof Enclosure / Canopy for optional
| Output Ratings |
| Generating Set Model | Prime | Standby | ||||
| APS-100 | 100KVA/80KW | 110KVA/88KW | ||||
| Generating Set Model | Length (L) mm | Width (W) mm | Height (H) mm | Net kg (lb) |
Gross kg (lb) |
|
| APS-100 | 2250 | 900 | 1300 | 1310 | 1360 | |
| APSS-100 | 2920 | 1080 | 1670 | 1730 | 1780 | |
| Dry = With Lube Oil Wet = With Lube Oil and Coolant | ||||||
| Ratings and Performance Data |
| Engine Brand | SDEC | |||
| Engine Model | SC4H160D2 | |||
| Alternator Brand | Stamford | |||
| Alternator Model | UC274C / UCI274C | |||
| Control System | Smartgen HGM6120N | |||
| Circuit Breaker Type | / | |||
| Frequency / Phase | 50Hz/ Three phase | |||
| Engine Speed ( RPM) | 1500Rpm | |||
| Fuel Tank Capacity (L) | 210 | |||
| Fuel Consumption rate (g/kW.h) | 198 | |||
| Model Type | Open / Silent | |||
| Standard Package | Plywood case/ Plastic | |||
| Noise Level@7m (dBA) | 70 | |||
| Generator set Manufacture | Acepow | |||
| Oil Consummption (g/kW.h) | ≦0.3 | |||
| Volatage (V) | 220/230/240 | |||
| Silencer Noise Reduction (dBA) | 10-20 | |||
| Engine Technical Data |
| Engine Model | SC4H160D2 | |||
| Engine Brand | Sdec | |||
| Number of Cylinders | 4 | |||
| Cylinders Arrangerment | Vertical in-line | |||
| Bore/Stroke (mm) | 105/124 | |||
| Speed (RPM) | 1500 | |||
| Displacement (L) | 4.3 | |||
| Compression Ratio | 16:1 | |||
| Aspiration | air-air intercooled | |||
| Starting method | Electric motor start | |||
| Engine Type | In-line,4 strokes, water-cooled,4 valves, Turbo charged, air-to-air intercooled | |||
| Prime power (kw) | 105 | |||
| Standby Power(kw) | 116 | |||
| Prime power (L/h) | 25 | |||
| Standby Power (L/h) | 27.7 | |||
| Governing Type | Electrical | |||
