Product Details:
Place of Origin:CHINA
Brand Name:YIHUA
Certification:CE,ISO, SASO
Model Number:APIV-75
Payment & Shipping Terms:
Minimum Order Quantity:1 PCS
Price:Negotiate
Packaging Details:NUDE PACKING,PLYWOOD CASE
Delivery Time:25 DAYS
Payment Terms:L/C, D/P, T/T
Supply Ability:10000SETS/YEAR

Description

Frequency:50HZ 60HZSpeed:1500RMP 1800RPM
Rated Voltage:400/230V,220/380VControl Panel:Digital Control System
Option 1:Soundproof,ATS(automatic Transfer Switch)Engine Brand:FPT
Generator Type:Canopy Diesel GeneratorColor:At Your Request
Fuel Tank:8hours, 12hours, 24hours, 48hoursGenerator Type:Silence Generator Set
High Light:

380V 3 Phase Silent Diesel Generator

,

75KVA 3 Phase Silent Diesel Generator

,

60KW low noise diesel generator



Continuous Use Diesel Generator Canopy Diesel Generator Fpt Iveco 60kw 75kva Canopy Genset Single Three Phase



Features :



Engine Brand: FPT

Alternator Brand: Stamford, Leroy Somer, Chinese Stamford for options

Controller: SmartGen, Deepsea, ComAp for options

Fuel tank: Big fuel tank for 8 hours continuous working, 12/ 24/ 48 hours built in or external fuel

A.V.R model: SX460

50℃ radiator

Fire extinguisher

Oil pump on the engine

ATS receptacle

Lockable battery isolator switch

Powder coated canopy

Vibration isolators between engine/Alternator and base frame

Integrated wiring design

High water temperature protection

Steel base frame with forkslots

Big daily fuel tank

Certificate: CE SASO

Condition: Brand New



Output Ratings
Generating Set ModelPrimeStandby
APIV-6075kVA60kW83kVA/66kW
Ratings and Performance Data
GENERAL
Engine modelNEF45SM2A.S500
Prime power/ standby power kw66/73
Number cylinders4
Cylinder arrangementin linea
Valves per cylinder2
Speed governordiesel 4 tempi
Injection systemdiretta
Air intakeTurbo aftercooler aria/aria
Bore mm104
Stroke mm132
Lubrication System
Oil sump capacity
max liter8,5
min liter5,5
Oil system capacity including filters liter12,8
Oil pressure at PRP kPa300-500
Oil temperature
normal °C—
max °C120
Oil consumption %fuel< 0,1
